W40 - Cast Iron Frame - Premium Efficiency - IE3


کد تاریخ قیمت تخفیف توضیح کوتاه اشتراک گذاری سفارش
2019549 1394-10-12 الکتروموتور WEG برزیل ضدجرقه با کلاس مصرفی IE3 - پوسته چدن ساخت برزیل Bookmark and Share سفارش

W40 - Cast Iron Frame - Premium Efficiency - IE3



High efficiency cast iron frame IP23 motor complying with IE3 efficiency levels according to IEC 60034-30.

Standard Features

  • Output: 11 kW up to 800 kW
  • Number of poles: 2 and 4
  • Frequency: 50 Hz
  • Frames: 160M up to 400J/H
  • Voltage: 380-415/660 V
  • Class “F” insulation (ΔT = 80K)
  • Degree of protection: IP23
  • Mounting: B3
  • Frame، end-shields and terminal box material: FC 200 cast iron
  • Cooling method: IC-01 according to DIN EN 60034-6
  • Ball bearings
  • Thermistors (PTC)، one per phase
  • Color: RAL 5009
    *For additional details about Inverter operation، please contact our technical support.
    *Special Insulation for voltages above 575V

Optional Available

  • Cable glands
  • Class “H” insulation
  • Roller bearings
  • Thermal protections: Thermostats or Thermoresistances (Pt-100) on windings or bearings
  • Space heaters
  • Other mounting configurations، including vertical and foot / flange mounted motors*
  • More options available، on request
  • Degree of protection WPI (IP24) for frame size 355J/H and 400J/H

    * Vertical flange mounting unavailable in frame size 280L

Typical Applications

  • Pumps
  • Fans
  • Kneader and mixer machines
  • Cutting and sawing machines
  • Pressing machines
  • Industrial equipment
  • Conveyor belts
  • Blowers
  • Compressors
  • Cranes
  • Packaging equipment
  • Other severe duty applications
