|2019566||1394-10-16||الکتروموتور Premium Efficiency Motors AEG با کلاس مصرفی IE3||سفارش|
Reducing energy consumption and CO2 emissions
AC motors have a significant impact on the total energy operation cost for industrial، institutional and commercial buildings. With this in mind Lafert embraced the challenges and brought a combination of IE3 Premium Efficiency and high reliability product to service this lucrative market.
Today، the major factor influencing the motor industry is energy efficiency driven by both increasingly demanding legislation and industry’s greater awareness of green issue responsibilities.
The PREMIUM EFFICIENCY IE3 motors provide compliance with the requirements of EU MEPS that has come into force January 1، 2015 and NEMA EPAct/EISA، which has been in force since December 2010 in the USA and January 2011 in Canada.
AMPE SERIES: nominal full load efficiency according to IE3 @ 400V-50Hz.
Three-phase motors up to 200 kW meeting the requirements of efficiency level in accordance with IEC 60034-30-1;2014
AMPH SERIES: nominal full load efficiency according to IE3 @ 460V-60Hz and NEMA MG 1 - table 12-12 (Premium Efficiency) @ 460V-60Hz.
Motors comply with EISA Directive (Energy Independence and Security Act، 2007).
Efficiency testing method CSA C390-10. Motors verified by UL Environment.
For a Global MEPS and Regulations please refer to Section “Standard & Regulation”.
IE3 PREMIUM EFFICIENCY
IE2 HIGH EFFICIENCY
IE1 STANDARD EFFICIENCY
E3 PREMIUM EFFICIENCY
IE2 HIGH EFFICIENCY
NEMA PREMIUM EFFICIENCY/EISA
NEMA ENERGY EFFICIENCY/EPAct
- Frame sizes: 80 to 315
- Power: 0.75kW to 200kW
- Poles: 2، 4، 6
- Frequency: 50Hz
- Frame sizes: 80 to 160
- Power: 0.75kW to 22kW
- Poles: 2، 4
- Frequency: 60Hz
- Construction: aluminium design
- Detachable feet، simple foot to flange conversion
- Four positions cable entry
- IP 55 protection
- Ease of maintenance
- Clean modern lines with RAL 9005 finish
- cURus Certification
- UL Energy Verified Certification
- CCC Certification (China Compulsory Certification)
- China Energy Label Certification - Grade 2
- Encoder mounting
- Forced ventilation
- Customised shafts of flanges
